Basic Info.

Model NO. 20mm-500mm Transport Package Plywood Case Specification 20mm-500mm Trademark OULIN Origin China HS Code 84779000 Production Capacity 600-1000 Sets Per Year

Product Description

Detail Information For Screw and Cylinder for Rubber Extrusion:

Application: for different kinds of rubber.

Customer's Requirement: extrude rubber continuously, stably and uniformly.

Screw's quality: bimetallic quality or nitriding quality.

Barrel's quality: bimetallic quality or nitriding quality.


Detail Information For All Rubber Screw and Barrel:

Brief introduction:
cold& hot feeding screw and barrel, such as pin type, conical type, venting type, injection type and etc, has good torque force& abrasion resistance, rubber will be extruded out uniformly and stably.

Specification:
1:For cold feeding screw and barrel
Diameter range: Ф40-Ф300MM
L/D ratio: 8-20

2: For hot feeding screw and barrel
Diameter range: Ф30-Ф250MM
L/D ratio: 4-8

3: for Pin type screw and barrel:
Diameter range: Ф60-Ф250MM
L/D ratio: 12-18

Base material :
38CrMoAlA(JIS SACM645) from BAOSTEEL company.
Alloy Layer: Fe, Wc, Si, Cr, Ni, Co, C, Mo, B and etc ( different quality has different formula).

Quality grade for screw and barrel:
Nitriding quality--------common quality type.
Bimetallic quality-------better abrasive& corrosive resistance, has different quality grade.

Heat treatment:
Advance hardening and tempering
Nitriding treatment

Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Alloy layer depth: 2mm-3mm
Alloy layer hardness: HRC56-64


OULIN SCREW:  YOUR LOYAL PARTNER FOR SCREW AND BARREL
