ItemUnitFDS930AFDS1100AFDS930BFDS1100B
Expansion   chamberDiametermmDn900Dn1100Dn900Dn1100Volumem30.91.40.91.4Usable volume
m3
0.75
1.0
0.75
1.0
    SteamEntryInch2"(DN 50)2"(DN 50)2"(DN 50)2"(DN 50)ConsumptionKg/cycle4~66~84~66~8PressureMpa0.6~0.80.6~0.80.6~0.80.6~0.8
Compressed  airEntryInch2"(DN 50)2"(DN 50)2"(DN 50)2"(DN 50)Consumptionm3/cycle
0.5~0.7
0.9~1.1
0.5~0.7
0.9~1.1
Pressure
Mpa
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
   DrainageUpper drain port
Inch4"(DN 100)4"(DN 100)4"(DN 100)4"(DN 100)Lower drain port
Inch4"(DN 100)4"(DN 100)4"(DN 100)4"(DN 100)Lower exhaust port
Inch3"(DN 80)3"(DN 80)3"(DN 80)3"(DN 80)    Material conveying lineInch6"(DN 150)6"(DN 150)6"(DN 150)6"(DN 150)

             Capacity10g/l230Kg/h320Kg/h230Kg/h320Kg/h15g/l320Kg/h550Kg/h320Kg/h550Kg/h20g/l450Kg/h750Kg/h450Kg/h750Kg/h30g/l670Kg/h850Kg/h670Kg/h850Kg/hConnected load /powerKw171915.517.5Expanded densityKg/m310~5010~4010~5010~40Density  tolerance%±2.5%±3%±2.5%±3%Overall dimension
(L*W*H)mm2700*4200*59002900*4500*59002700*4200*59002900*4500*5900WeightKg2700320027003200
