Basic Info.

Max. Transport Distance 15m Max. Charge Volume 25L Transport Package Wooden Package Specification CE Trademark chenxing Origin Jiangsu of China HS Code 8477800000 Production Capacity 2000sets/Year

Product Description

Description:
The unit is used to realize the airflow conveying of granulated resin by means of technology of low vacuum. It can be used with a hopper dryer to automatize dry material-supplying.
Features:
1. Host machine separated from the hopper, easy and safe to operate;
2. Independent filter for easy cleaning;
3. Stainless hopper;
4. Microcomputer controlled;
5. Alarm for overload and lack of material;
6. High-speed rectifier motor of small footprint and strong suction force for new material for XC-XF-700G;
7. Induction high pressure pump of low noise and long service time for XC-XF-800G and XC-XF800G2;
8. Reverse cleaning for XC-XF-800G and XC-XF800G2. Auto raw AES loader

Main technical parameters:

Model			ZJ100	ZJ200	ZJ400	ZJ600	ZJ1000
Max. wind pressure  (pa)			9800	9800	13000	14000	16000
Max. air. volume  (m3/min)			2	2	2.8	3.4	4.5
Motor Power  (kw)			1.1	1.1	1.5	2.2	5.5
Rotating  speed  of  motor  (r/min)			2800
Transport  capacity(kg/h)	Transport  distance  (m)	5	100	200	400	600	1000
		10	-	150	300	450	700
		15	-	-	-	360	500
Aspirating  charging  door  volume  (L)			5	10	15	20	25
Internal  diameter  of  transfer  soft  pipe  (mm)			40	40	40	50	50
Internal  diameter  of  aspirating  soft  pipe  (mm)			40	40	50	50	60
Weight  (kg)			60	75	90	100	130
