Basic Info.

Model NO. JC-340D Production Capacity 50 Sets Per Month

Product Description

JC-340D Performance features:
1. Speed reducer, main-rotating connection, main shaft are on line (to decrease driving error) for mechanical transmission.
2. Sensor controls are adopted in pneumatic system. PLC control makes the whole machine run smoothly, keeps synchronous stability during the products are to be packed in multi-labor, long- distance.
3. Main motor non-stop speed regulating, the travel adjustable at will, simple and convenient to change the mould, manipulator traction, stable running.
4. Deep forming

Punch frequency	15-40(times/min)
Mould colling	tap water recycle water 60 L/H
Max forming area	330*110 mm
Max forming depth	48mm
stroke	60-160 mm
compressed air(mpa)	0.6-0.8
total power	4.5
PVC hard pieces	0.15-0.5*340
Over dimension	1900*790*1700 millimeter
weight	950 kg
