Basic Info.

Model NO. PPD-SAW500 Speed Max900m/Min Power 3kw Electricity 220/380/415/450V,3phase Transport Package Plywood Case Specification CE, SGS, ROHS Trademark PPD Origin China(Mainland) HS Code 84778000 Production Capacity 10units/Month

Product Description

Multi-function Semi Auto Stretch Wrap Film Winding Machinery  is a model of designed for rewind jumbo diameter of parent roll into a smaller diameter.By different buyer'request,we have developed full range of this machine,manual model,semi-automatic model,fully automatic model.
Semi automatic model is very user friendly,fast in production speed.
After rewinding from the jumbo roll,the rewinding roll' appearance,quality,technical specification.
This machine is suitable for PE stretch film,pallet stretch wrap,stretch wrapping film,food stretch wrap film,PVC food cling film etc with high speed production.

Main technical specs:

Max width of parent roll	500mm
Max outer diameter parent roll	500mm
Rewind roll width	max500mm
Rewind roll maximum diameter	300mm
Inner diameter of parent roll	3inch
Inner diameter of rewind roll	2/3inch
Speed	max900m/min
Power	3kw
Electricity	220/380/415/450v,3phase
