• Model NO.：PEDK-9060
• Applicable Material：Nonmetal
• Type：Oscillating Mirror
• Laser Classification：Fluid Laser
• Engraving Method：Vector Engraving
• Engraving Machine Type：Laser Engraving Machine
• Control：Automatic
• Current：AC
• Laser Type：CO2
• Usage：Plastic
• Working Area：600*400mm
• Laser Power：Standard 50W , Selective 80W
• Engraving Speed：1-60000mm,Min
• Cutting Speed：1-10000mm,Min
• Repeat Location Accuracy：0.0125mm
• Transport Package：Export Sea-Worthy Packing or Air-Worthy Packing
• Specification：ISO9001: 2000,CE
• Trademark：Perfect Laser
• Origin：China
• HS Code：845610
• Production Capacity：1000 Units, Month

Basic Info.

Model NO. PEDK-9060 Applicable Material Nonmetal Type Oscillating Mirror Laser Classification Fluid Laser Engraving Method Vector Engraving Engraving Machine Type Laser Engraving Machine Control Automatic Current AC Laser Type CO2 Usage Plastic Working Area 600*400mm Laser Power Standard 50W / Selective 80W Engraving Speed 1-60000mm/Min Cutting Speed 1-10000mm/Min Repeat Location Accuracy 0.0125mm Transport Package Export Sea-Worthy Packing or Air-Worthy Packing Specification ISO9001: 2000/CE Trademark Perfect Laser Origin China HS Code 845610 Production Capacity 1000 Units/ Month

Product Description

Acrylic Leather Wood CO2 Laser Engraving Cutting Machine
(Model: PEDK-9060)
Contact: Lydia

For cutting and carving on plexiglass products, acrylic art & crafts panel, lenses, wood &cutting carving, advertising materials, crystal characters, easel, packing boxes, models, toys andfurniture etc. Due to its various applications, the machine can also be called laser cutting and engraving machine, laser engraving plastic, laser cutting plexiglass, plastic engraving machine, plexiglass laser cutting machine, laser engraving supplies.

Product features:
1. The water cooling and alarm protection system adopts the CW-3000 chiller temperature display to avoid over-combustion and protect the power over-water circulation.
2. High cutting accuracy, no focal and yellow edges, the laser cutting and engraving machine isequip with high precision metal rails and stepper motors, and with honeycomb platform, perfect engraving 1X1 mm letters, to meet the needs of highly accurate work.
3. LCD touch screen, CO2 non-metallic laser cutting and engraving machine supports USB interface and DSP offline control system, external USB data cable or U disk, support BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG , DXF and other file formats.
4. CO2 non-metal laser engraving plastic machine can be equipped with American imports of focusing lens and lens, China's Leadshine stepper motor, Japan's imported servo motor, a variety of configuration and diverse, there is always one to meet your needs.
5. The CO2 non-metal laser cutting plexiglass machine independently developed by PerfectLaser can set parameters, enable envelope cutting, set the engraving area, and perform frame cutting.

Samples:


Unique advantages:


Technical data:

Model	PEDK-9060 Laser Cutting And Engraving Machine
Laser Power	60w / 80w / 100w / 130w
Engraving Area	900×600mm
Engraving Speed	0-60000mm/s
Cutting Speed	0-10000mm/s
Repeating Location Accuracy	±0.0125mm
Working Voltage	220V ±10% 50HZ
Machine Power	900w
Controling System	CNC professional controlling system
Supporting Graphics Formats	BMP,HPGL,JPEG,GIF,TIFF,PCX,TAG,CDR,DWG,DXF
Cooling Mode	CW-3000 Water Chiller with protection function
Auxiliary Devices	Exhaust fan & exhaust pipe
Cutting Platform	Professional honeycome / strip work table
Power Control Mode	Laser power and moving system cooperate
Control Software	Original Perfect Laser laser engraving and cutting software
Machine Size	1400*960*1150mm

Company information:
Perfect Laser was founded in 1995, located in Wuhan city. We have 24 years experience in this field.  our products get favorable sales success and outstanding reputation not domestically in China but also popular in more than 180 countries, Our company has the CE certificate, ISO9001:2000 ISO  quality system certificate.

Here is the website:  perfectlaserco.en.made-in-china.com.

We produce 12 series product ranges and 200 different models, attached please kindly find the machine styles and the related price. Also, welcome to visit our website perfectlaserco.en.made-in-china.com to get an overall idea about our products and quality.
