Basic Info.

Model NO. SJ-50/FM600 SJ-55/FM800 SJ-60/FM1000 Certification CE Transport Package Plastic Film Packing Specification CE Trademark E-light Origin China HS Code 84431980 Production Capacity 600sets/Year

Product Description

CHARACTERISTICS OR MAIN TECHNICAL VARIABLES:

Its extruder, cylinder and screw rods are made of quality alloy steel that have been notarized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity.

It is applied to blowing the plastic films like low density polythene (LDPE), high density polythene (HDPE)and linear low density polythene (LLDPE), It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.

Model	SJ-50/FM600	SJ-55/FM800	SJ-60/FM1000
Screw Diameter	50mm	55mm	60mm
Screw Ratio	L/D30.1	L/D30.1	L/D30.1
Screw Speed	10-120r/min	10-120r/min	10-120r/min
Power of Main Motor	18.5kw	22kw	30kw
Max. Extrusion output	30-60kg/h	40-80kg/h	50-100kg/h
Max. Folding Width of Film	600mm	800mm	1000mm
Single-sided Thickness of Film	0.008-0.10mm	0.008-0.10mm	0.008-0.10mm
Sub-master Machine Lift Scope	800mm	1000mm	1200mm
Total Power	28kw	36kw	42kw
Weight of machine	2600kg	3000kg	3500kg
Overall Dimensions (L*W*H)	4600mmX2600mm X4000mm	4800mmX2800mm X4300mm	5000mmX3000mm X4800mm
