600m Deep Mineral Exploration/Investigation Rotary Hydraulic Core Drilling Equipment (XY-3)
Ruian Shengxiang Packaging Machinery Co., Ltd.Base Info
Description
Overview
Product Description
3. Anti-torque device has been equipped to deter rotation of the drill's spindle, suitable for directional drilling.
4. Diesel engine or electromotor is available to satisfy various engine demands. Mud pumps, drill stems and faucets are easy to assembly.
5. Equipped with automatic transmission, clutch, universal drive shaft and other high quality general parts, this surface coring equipment enjoys long service life, easy movement and replacement.
6. Connecting rod reinforcement spring clamp and hydraulic chuck enjoy novel structure, large clamping force, long service life and reliable performance.
7. Excellent monitoring and alarming capacity of parameter, including torque, drilling pressure, speed, etc. helps to prevent and reduce drilling accidents of coring rigs.
8. The pressure indicator installed at the bottom of hole helps users to observe the pressure variation during drilling working.
Product ParametersName Electrical motor Diesel engine model Type Y200L-4B35 YC4D60-D21 Power (Kw) 30 40 Speed (r/min) 1480 1500 Chisel in the ability Φ50 Drilling rod Drilling depth >600 m Swivel head Spindle speed (r/min) Clockwise: 41-1071 Contrarotate: 46144 Spindle Max output-torque (Nm) 3200 (65r/min) Spindle diameter (mm) 76 circumvolve angle 0-360º Upgrade capacity (KN) Rated:60 Pressurizes the ability (KN) Rated:45 Stroke(mm) 600 Hoist Type Planetary Type Single-rope lifting-force (KN) Max 32 Single-rope lifting-speed (m/s) 0.72-2.38 Roll diameter (mm) 220 Steel cable diameter (mm) 14 Hydraulic system Type of oil pump CBTLFT-E416/E410-ALH6 Displacement (ml/r) 16+10 System press (MPa) 8 Mobile oil cylinder stroke (mm) 460 Dimensions (L*W*H) (mm) 2760*920*1880 (including motor) 3120*920*1880 (including Diesel engine) Weight (Kg) 1300
XY-3 coring equipment is a new type of coring drilling rig developed to meet multiple drilling requirements, especially diamond drilling. It is designed for engineering geological exploration, small-scale water well drilling and engineering construction for highway, railroad, hydropower, harbor, etc. Electromotor or diesel engine is available to facilitate operation.
Product Features1. This coring drill rig can meet demands of multiple drilling applications, including diamond rope sampling, directional drilling, impact gyration, reverse circulation continuous sampling, and so forth.
2. A wide rotational speed range is available for this coring rig to satisfy demands of drilling applications.3. Anti-torque device has been equipped to deter rotation of the drill's spindle, suitable for directional drilling.
4. Diesel engine or electromotor is available to satisfy various engine demands. Mud pumps, drill stems and faucets are easy to assembly.
5. Equipped with automatic transmission, clutch, universal drive shaft and other high quality general parts, this surface coring equipment enjoys long service life, easy movement and replacement.
6. Connecting rod reinforcement spring clamp and hydraulic chuck enjoy novel structure, large clamping force, long service life and reliable performance.
7. Excellent monitoring and alarming capacity of parameter, including torque, drilling pressure, speed, etc. helps to prevent and reduce drilling accidents of coring rigs.
8. The pressure indicator installed at the bottom of hole helps users to observe the pressure variation during drilling working.
Product Parameters
The technical parameters of the XY-3 Drilling Rig:
Engine
