ABC High Speed Plastic Bag Film Blown Machine
Saame Tools (Shanghai) Import & Export Co., Ltd.Base Info
Description
ModelABC-45-50-45/1200 ABC-50-55-50/1400 ABC-55-65-55/1600 ABC-65-75-65/1800Width of the film250-1100mm 300-1300mm 500-1500mm 500-1700mmThickness of the film0.006-0.15mmThe max output135kg/h 155kg/h 185kg/h 205kg/h
According to different width,thickness of film, die size and raw material characteristics to changeRaw materialHDPE/LDPE/LDPE/RECYCLE/CACO3Power consumption28kw/h 32kw/h 35kw/h 40kw/hWeight4200kg 5200kg 9800kg 10200kgOverall dimension(L*W*H)m6.5*2.7*5.8 6.5*3*6.2 6.5*3.8*6.8 6.8*4*7.5Extruder unitDiameter of screwΦ45/50/45 Φ50/55/50 Φ55/65/55 Φ65/75/65
SACM645 wearproof Alloy steel,five years guaranteeL/D ratio of screw30:1Rotation speed of screw10-120r/mBarrel FanZone 3 barrels install over-temperature fanGear box146# 173# 200# 225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation systemMain motor15kw 22kw 30kw 37kw
100% Original three-phase variable frequency motor Equipped with inverter controlDie head unitDie diameter
60mm 80mm 120mm 250mm 360mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effectrotary electric machine motor 0.75kw rotation mode 360 degreeCool unitAir ring type
LDPE double vents vacuum air ring
HDPESingle outlet air ringAir ring materialHigh quality Taiwan cast aluminum alloy air ringBellow power 4kw 5.5kw 7.5kw 11kw Shanghai production of high-pressure mute fanTraction unitWidth of take up roller1200mm 1400mm 1600mm 1800mm Traction roller materialsilicone roller
NBR rollerTake up motor1.5kw 2.2kw 3.0kw
Installation of RV series reducer variable frequency motor inverter controlTake up speed100m/minconstant tension traction motor1.5kw frequency control 10N.m torque controlwidth of traction roll700mm 900mm 1200mm 1400mm Embossing rollerhot embossing unit
cold embossing unitLambdoidal boardWooden flannel wrapped
Aluminum roller guide Bubble stabilizing ringElectric aluminum roller guide
Manual wood floor Guide rollerAluminum guide roller (HV300-HV700) surface treatmentWinding unitWinding typeSurface friction rewinding, manually change the volumeDrive typeTorque motor equipped RV reducerFilm expanding rollerSmoothing rollThe second traction partIndependent torque control constand tension controlComputer control type7-inch touch screen + process control system
Automatic air supply device Service
Our Advantage:
1. First-class and professional service team offer one-stop intimate service. 18 senior technical experts, more than 20 after sales service staff.
2. No charge for training the technician, let you have nothing to worry about!
3. Five yearafter-sales service and mechanical parts lifetime warranty.
4. Life-long free for offering all kinds of technical service and 24 hours after service.(no worry about the time differences)
Order step
step1. Please let us know which product you like. the model and size, the offers will be sent to you within 24 hours.
step2. We make proforma invoice (PI) for you.
step3. Please check and confirm the PI
step4. Once we confirmed the order, please pay it soon.
step5. After payment, all goods will be sent to you in the delivery time.
