Industry Cooking Jacketed Kettle for Commerical
NINGBO HAISHU JUDIN PACKING PRODUCTS CO., LTD.- Usage：Biscuit, Cake, Pizza, Bread, Food Industry
- Power Source：Electric
- Timing Device：Without Timing Device
- Type：Cooking Kettle
- Voltage：All Is Ok
- Customized：Customized
Base Info
- Model NO.：KQ100L-1000L
- Name：Industry Cooking Jacketed Kettle for Commerical
- Double Jacketed Kettle：Heating and Mixing
- Jacket Kettle Capacity：300L ,500L, 600L, 1000L
- Mixer：Scrapper Mixer, Normal Mixer
- Kettle Material：Ss 304,316
- Temperature：Above 90degree
- Kettle Type：Vertical ,Tilting
- Jacket Kettle：Heating by Electricity, Steam
- Delivery：10 Days
- MOQ：1 Set
- Transport Package：Standard Export Wooden Box
- Specification：ISO
- Trademark：KQ
- Origin：Shanghai, China
- HS Code：8479820090
- Production Capacity：2000set ,Year
Description
KQ100
KQ150
KQ200
KQ300
KQ400
KQ500
Capacity L
100
150
200
300
400
500
Jacketed pressure
Mpa
< 0.2
Evaporation capacity
kg/h
40
50
65
75
100
150
Heat area
m 2
0.45
0.76
1.0
1.15
1.44
1.90
Energy consumption
kg/h
44
55
72
90
110
165
N.W.
kg
190
210
230
320
360
485
LxWxH
mm
800X650X830
1350X650X1100
1400X700X1100
1450X800X1110
1500X850X1140
1600X900
ACKET Kettle PART
Capacity: 300L TO 1000L
Material: SS304
Heating by Electric (380V, 50HZ)
* Type: with Jacketed wall
* Internal shell thickness: 3 mm
* Jacket thickness: 3 mm
* Accessories
:
(1)Lid able to open on the top
(2) Tilt able 90degree
(3) Heat transfer oils (water) Inlet/outlet,
(4) Heating tube, (5) Electric cabinet, (6) Reduction gears, (7) Rack & blender etc.
(8)The electric motor (0.75KW/1.1KW/2.2KW/3KW/5.5KW, 380V, 50HZ)
Industry Cooking Jacketed Kettle for Commerical
