Fiber Laser Cutting Machine
King Garden Paper Product Co., Ltd.- Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Textile Machinery, Aerospace Industry, Automotive Industry, Shoemaking Industry, Woodwork Industry, Advertising Industry
- Cooling System：Air Cooling
- Technical Class：Pulse Laser
- Applicable Material：Metal
- Structure Type：Desktop
- Laser Classification：Solid Laser
Base Info
- Model NO.：FLT-6016L
- Laser Technology：Laser Fusion Cutting
- Transport Package：Plastic Covering
- Specification：FLT-6016L
- Trademark：HAVEN
- Origin：China
- HS Code：8462
- Production Capacity：50 Units,Month
Description
Basic Info.
Model NO. FLT-6016L Laser Technology Laser Fusion Cutting Transport Package Plastic Covering Specification FLT-6016L Trademark HAVEN Origin China HS Code 8462 Production Capacity 50 Units/MonthProduct Description
Fiber Laser Cutting Machine
Main features:
FLT-6016L is an economical and practical laser pipe cutting machine in combination with market demand for end-users of bulk pipe processing. The model is extremely cost-effective, It can cut 6 meters and the tailing is 70mm, which is extremely adaptable. It is an ideal choice for the majority of pipe processing enterprises.
From configuration selection to assembly process, to post-training and after-sales service, the machine truly creates a laser cutting machine that customers can afford!
Main specification:
| Model | FLT-6016L | unit |
| Tube cutting size x Thickness | Round Φ20-φ160 x 8 Square tube Side length ≤110 x 6 Rectangular tube diagonal ≤160 x 6 Tube length ≤6500 | mm |
| Max. weight of single tube | 100 | kg |
| CNC control | 4 Axis --- X,Y,Z,W | |
| X aixs distance | 160 | mm |
| Y aixs distance | 6900 | mm |
| Z aixs distance | 120 | mm |
| X/Y aixs positioning accuracy | ±0.03/1000mm | mm |
| X/Y aixs repeat positioning accuracy | ±0.02/1000mm | mm |
| Acceleration | 1.5G | m/s² |
| X/Y aixs Max moving speed | 70 | m/min |
| Chunk Max rotary speed | 150 | r/min |
| Tailing length | ≥70(according to tube maybe different) | mm |
| Machine size | About 8900×1700×1300 | mm |
| Laser power | 1000 | w |
| Control system | Cyp-tube | |
| Power consumption | 12KW | Kw |
| Electric | 380V/50Hz | V |
Main configurations:
| Model | Brand | Orignal/Country | Quantity |
| Servo motor | Schneider | France | 5 Set |
| Guild | Dinghan | Taiwan | Several |
| Gear | APEX/J&T | Taiwan | Several |
| Servo reducer | Motovario | France | 3 Set |
| Front and rear pneumatic chuck | JQ | China | 1 Set |
| Pneumatic Components | Airtac | Taiwan | Several |
| Laser soruce | Raycus | China | 1 EA |
| Laser head | RAYTOOLS | China | 1 EA |
| Water chiller | Hanli | China | 1 EA |
| Air conditioning (option) | Tongfei | China | 1 EA |
| Low voltage electrical components | Chint | China | Several |
| Industrial controller | Yanhua | China | 1 EA |
| Oiling system | Dingshen | China | 1 Set |
| CNC Control system | Cyp-tube | China | 1 Set |
