• Model NO.：CSK-15
• Stainless Steel：304
• Transport Package：Wooden Box
• Specification：CE ISO
• Trademark：HELPER
• Origin：China
• Production Capacity：30sets Per Month

Basic Info.

Model NO. CSK-15 Stainless Steel 304 Transport Package Wooden Box Specification CE ISO Trademark HELPER Origin China Production Capacity 30sets Per Month

Product Description

CSK-15 Fully Automatic Dual Sausage Clipper

The machine is driven by servomotor with compact structure and reliable transmission. The machine body, main parts and transmission parts, are all made of excellent aluminum alloy and stainless steel. The integrated mechanical property of machine can Satisfy your different requirements.

Feature of great wall clipping machine:
*Smart design and compact structure
*Elegant Great Wall Clips make high grade appearance for clipping
*Clip speed: 0-120times adjustable
*Clip model available: Great Wall type
*Flat width of casing available: 30mm-120mm
*Control parts: Human-machine interface PLC, the electromagnetical touch switch is controlled by SCM
*Cut knife is driven pneumatically

Clip available Speed of clipping(times) Motor power(kw) Power supply(v) Great Wall Type 0-120adjustable 3.5 single-phase alternating current220± 10% (servomotor) three-phases alternating current380± 10% (electromagnetical onoff)

Air source(Mpa) Casing available(mm ) Air consumption(m 3 ) Dimension(mm) work presure0.5-0.6(for cutter) flat diameter is from30-120 0.0064(for cutter) 760× 750× 1770
