Nhm16-1600 Radial Piston Hydraulic Motor
Guangzhou Cospack Packaging Technology Co., Ltd.- Certification：RoHS, ISO9001
- Excitation Mode：Excited
- Power Rating：3000W
- Casing Protection：Protection Type
- Speed：Low Speed
- Type：Piston Motor
Base Info
- Model NO.：NHM1,2,3,6,8,11,16,31
- Usage：Hydraulic Oil
- Standard or Non-Standard：Standard
- Warranty：One Year
- Structural：Piston Type Motor
- Hydraulic Power Units：Screw Pump
- Hydraulic Fluid：Synthetic Hydraulic Oil
- Hydraulic Actuator：Combination Hydraulic Cylinders
- Hydraulic Motor：Piston Hydraulic Motor
- Application：Heavy-Duty Machine
- Type of Loading：Radial Motors
- Transport Package：Carton Box, Wooden Case, Pallet
- Specification：CE, ISO9001
- Trademark：Blince
- Origin：China
- HS Code：8412291000
- Production Capacity：10000
Description
ModelDisplacement Pressure Torque Speed range Rated Max Rated N.m/Mpa NHM1-63 77 25 32 248 11 15-1500 NHM1-80 91 25 32 335 13 15-1250 NHM1-100 96 25 32 355 14 15-1000 NHM1-110 113 25 32 419 17 15-1000 NHM1-125 126 20 25 371 19 15-1000 NHM1-140 138 20 25 410 20 15-1000 NHM1-160 156 16 20 376 24 15-1000 NHM1-200 196 16 20 464 19 15-1000 NHM2-100 113 25 32 419 17 15-1250 NHM2-125 138 25 32 512 20 15-1250 NHM2-150 159 25 32 588 24 15-1000 NHM2-175 180 20 25 532 27 15-1000 NHM2-200 207 20 25 611 31 8-800 NHM2-250 235 16 20 556 35 8-630 NHM2-280 276 16 20 653 41 8-500 NHM3-175 181 25 32 670 27 8-1000 NHM3-200 201 25 32 743 30 8-800 NHM3-220 222 25 32 819 33 8-800 NHM3-250 254 20 20 752 38 8-630 NHM3-300 289 20 20 856 43 8-500 NHM3-350 340 20 20 1000 50 8-400 NHM3-400 380 18 22.5 1008 56 8-350 NHM6-400 397 25 32 1469 59 5-630 NHM6-450 452 25 32 1672 67 5-630 NHM6-500 491 20 25 1451 73 5-500 NHM6-600 594 20 25 1756 88 4-500 NHM6-700 683 16 20 1616 101 4-400 NHM6-750 754 16 20 1785 112 4-320 Model Displacement Pressure Torque Speed range Rated Max Rated N.m/Mpa NHM8-700 710 25 32 2626 105 4-400 NHM8-800 810 20 25 2396 120 4-400 NHM8-900 889 20 25 2629 131 3-350 NHM8-1000 1000 16 20 2366 148 3-300 NHM11-700 707 25 32 2612 104 4-400 NHM11-800 784 25 32 2899 116 4-400 NHM11-900 894 25 32 3306 132 4-400 NHM11-1000 981 20 25 2902 145 3-320 NHM11-1100 1104 20 25 3265 163 3-320 NHM11-1200 1234 16 20 2929 182 3-320 NHM11-1300 1301 16 20 3079 192 3-250 NHM31-2500 2553 25 32 9438 378 2-200 NHM31-2800 2680 20 25 7935 397 1-200 NHM31-3000 3063 20 25 9057 453 1-200 NHM31-3150 3218 20 25 9518 476 1-160 NHM31-3500 3561 20 25 10530 527 1-160 NHM31-4000 4153 18 22.5 11053 614 1-160 NHM31-4500 4522 16 20 10698 669 1-160 NHM31-5000 4828 16 20 11423 714 1-160 NHM70-5000 4968 20 25 14626 731 1-160 NHM70-5400 5452 20 25 16125 806 1-160 NHM70-6000 5984 20 25 17697 885 0.5-125 NHM70-6300 6540 18 22.5 17408 967 0.5-125 NHM70-7000 7122 16 20 16849 1053 0.5-125 NHM100-6300 6770 20 25 20021 1001 0.5-125 NHM100-8000 8298 20 25 24541 1227 0.5-125 NHM100-10000 9982 20 25 23617 1476 0.5-100 NHM160-12500 13334 16 20 39433 1972 0.3-83 NHM160-16000 16039 20 25 37948 2372 0.3-63
Product application:
NHM1/2/3/6/8/11/16/31 Hydraulic motors are widely applied in agriculture machinery, fishing machinery, plastic industry, mining, and construction machinery, especially fitted to lower load applications, such as plastic injection mold machine, cleaner, grass cutter, etc.
Blince company:
Our company main product is orbit motor like (OMM/OMP/OMR/OMH/OMT/OMS/OMV), Radial Piston Motor(NHM 1/2/3/6/8/11/16/31), hydraulic pump (PV2R series, V/VQ series, SQP series) and steering control unit replace OPSC/OSPB.
