• Model NO.：GD150-S
• Capacity：150kg,Hr
• Candy Weight：as Per The Candy Size
• Depositing Speed：55-65n,Min
• Steam Requirement：250kg,Hr, 0.5-0.8MPa
• Compressed Air：0.2m3,Min, 0.4-0.6MPa
• Power：18kw,380V
• Length：15m
• Machine Weight：3500kg
• Transport Package：Wooden Case
• Specification：CH, ISO9001, ISO2000
• Trademark：SHANGHAI SHINWEI MACHINERY
• Origin：Shanghai
• HS Code：84382000
• Production Capacity：150kg,Hr

Basic Info.

Model NO. GD150-S Capacity 150kg/Hr Candy Weight as Per The Candy Size Depositing Speed 55-65n/Min Steam Requirement 250kg/Hr, 0.5-0.8MPa Compressed Air 0.2m3/Min, 0.4-0.6MPa Power 18kw/380V Length 15m Machine Weight 3500kg Transport Package Wooden Case Specification CH, ISO9001, ISO2000 Trademark SHANGHAI SHINWEI MACHINERY Origin Shanghai HS Code 84382000 Production Capacity 150kg/Hr

Product Description

The processing line is a compact unit which can continuously produce various kinds of hard Candies under a strict sanitary condition.It is also an ideal equipment which can produce Out good quality products with the saving of both the manpower and the space occupied.
1) PLC /computer process control available;
2) An LED touch panel for easy operating;
3) The standard production capacity is150kgs/h;
4) The main parts is made of hygienic Stainless Steel
5) Optional (mass) flowing controlled by Frequency inverters ;
6) In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;
7) Dosing pumps for the automatic injection of colors, flavors and acids;
8) Use AUTOMATIC STEAM CONTROL SYSTEM instead of manual steam valve which Controls a stable steam supply to the microfilm cooker;
9) "two-color stripe depositing", "two-color double layers depositing", "central filling", "clear" hard candies & Jelly candies & lollipop & toffee and etc.Can be made as option.
10) Moulds can be made according to the candies samples provided by the customer.

Max candy weight  As per the candy size
speed  55~65 n/min
Steam consumption
Steam pressure
300kg/h, 0.5~0.8MPa
Compressed air consumption
Compressed air pressure
0.5m3/min,
0.4~0.6MPa
Electric power needed  24kW/380V
Total length(m)  15
Gross weight  8500 kgs
